Floor Plans - First Floor Plan(x2) Floor Plans - Second Floor Plan(x2) 4 Elevations - Front - Back - Right - Left (x2) Cross Section 1 Longitudinal Cross Section(x2) Cross Section 2 Transverse Cross Section(x2) Foundation Plan (Wood Floors)(x2) First and Second Floor Framing Plan and Roof Framing Plan(x2) Stairs Cross Sections (x2) Wall Sheathing Plans (x2) Roof Sheathing Plans (x2) Additional 1st and 2nd Floor Plans for Writing in your own Electrical Layout for Your Personal Customization (x1) These Will be Additional Costs and/or Performed by your General Contactor: -The electrical layout of the house will be done with an Electric Contractor, your General Contractor, or the Owner who will assist in the Electrical Permit Application process. For Customization Availability is why this is Better. (Note: I will enclose an extra copy of the first and second floor plans to make this easier.) -The plumbing will be done with a Plumbing Contactor, your General Contractor, or the Owner who will also assist in the Plumbing Permit Application process. (Note: I will enclose an extra copy of the first and second floor plans to make this easier.) -The HVAC or mechanical part will be done with an HVAC Contractor, your General Contractor, or the Owner who will assist in the Mechanical Permit Application. (Note: I will enclose an extra copy of the first and second floor plans to make this easier.) -Engineers must Provide Details and Notes for everything requiring an Engineer such as: Sheer Wall Nailing, Tie Downs, Uncommon Foundation Details, and the Beam Calculations. These Need to be Drawn after the lot is Certain: -Site Plans (x4) These can be added at $50 per hour or outsourced. An example will be below (coming soon). -Location, type of fuel and efficiency rating of all heating and/or air conditioning systems. -The Elevation should show the true site Conditions (Topography of lot).
